DHV823 HV 16.8KG Coreless Full Aluminum Case Servo

Servo HV Coreless
Features
Get Samples Now

Applications

Specifications

Performance

  • Voltage
    7.4v
  • Rated torque
    16.5kg·cm
  • Rated current
    3200mA
  • Stall torque
    16.5kg·cm
  • Stall current
    3200mA
  • Operating speed
    {content:operating_speed}
  • No load current
    950mA
  • Idle current
    20mA

Mechanical

  • Dimensions
    40*20*39mm³
  • Weight
    67.5g
  • Limit angle
    205°±1°
  • Excessive play
    ≤0.5°
  • Shell material
    full CNC aluminum
  • Gear material
    Titanium
  • Spline
    25T
  • Bearing type
    DUAL BB
  • Motor type
    Coreless Motor
  • Angle sensor
  • Storage temperature
    -20℃～60℃
  • Operating temperature
    -10℃～50℃

Control & Protection

  • Signal type
    PWM
  • Rotation angle
  • Pulse width range
    900→2100 μsec
  • Neutral position
    1500 μsec
  • Dead band
    /
  • Rotating direction
    counterclockwise
  • Feedback
    /
  • Protection type
    /

Reliability

  • Load life
    /
  • Noise
    /
  • Waterproof
    /

Dimension Drawing

dimension drawings

Downloads

Specification
2D Drawings
3D Model
Usage Guidelines

FAQs

Select 2D drawings download format

PDF
DWG

Select 3D drawings download format

STEP
IGES
STL
